Product Description

The RICH SOLAR MEGA 250 is a 250-watt 12V solar panel designed for RVs, vans, boats, cabins, DIY solar power, off-grid, and marine applications. Its compact design helps make it suitable for installations where space is limited while still delivering dependable solar power output. Built with N-Type TOPCon technology, a 64-cell monocrystalline module, AR-coated glass, and a reinforced aluminum frame, this panel is designed for outdoor solar use. It includes pre-drilled mounting holes, MC4 connectors, and pre-attached cables for easier installation.

KEY FEATURE

  • 250W maximum power output
  • 12V solar panel design
  • 25.1% maximum cell efficiency
  • 0~+5W positive power tolerance
  • 64-cell monocrystalline module
  • N-Type TOPCon technology for higher efficiency and lower degradation
  • Half-cut and 16-busbar design helps reduce power loss and minimize hotspots
  • Bypass diodes help maintain stable performance in partial shade
  • Low-light performance for cloudy or low-light conditions
  • IP68 weatherproof junction box and IP67 connectors
  • Certified to withstand up to 2400 Pa wind load and 5400 Pa snow load
  • Impact resistant against hail up to 35 mm at 97 km/h
  • Pre-drilled holes provide multiple mounting options
  • MC4 connectors with pre-attached cables
  • Reinforced 1.3mm thick aluminum frame for strength and corrosion resistance



Solar Panel Dimensions

Specifications



Maximum Power ( Pmax): 250W
Maximum Power Voltage (Vmp): 18.9V
Maximum Power Current (Imp): 13.2A
Open Circuit Voltage (Voc): 22.8V
Short Circuit Current (Isc): 13.7A
Maximum System Voltage (Vmax): 1500VDC
Temperature Range: -40°F~ +185°F
Weight: 26.9 lb
Dimensions: 60.6 Ă— 29.9 Ă— 1.2 in

DOWNLOADS

Tough Solar Panels for
Tougher Environments

  • IP68 Weatherproof Build: Durable IP68 junction box and IP67 connectors for all-weather reliability.
  • Certified Strength: Withstand up to 2400 Pa wind and 5400 Pa snow load for dependable performance.
  • Impact Resistant: Durable against hail up to 35 mm at speeds of 97 km/h, ensuring long-term reliability.

Superior Performance and Reliability

  • Premium Solar Cells: Built with Grade A+ cells for exceptional efficiency, stability, and long-lasting reliability.
  • Rigorous Testing: Each panel undergoes 30+ mechanical and electrical tests, including PID resistance and EL diagnostics, to ensure quality.
  • Low-Light Performance: N-Type TopCon cells, 16 busbars, and AR-coated glass work together to capture more light and deliver steady power even in cloudy or low-light conditions.

Compact Solar Panel with 25.1% Efficiency

  • Compact Size: 10% smaller than standard 10BB 250W panels, perfect for tight RV/van/trailer roofs.
  • N-type TopCon Technology: Higher efficiency, lower degradation, longer lifespan.
  • Half-Cut + 16-Busbar Design: Reduces power loss, minimizes hotspots, and maximizes power output.
  • Shading-Resistant: Bypass diodes maintain stable performance in partial shade.

Quick Install, Durable Solar Panel

  • Easy Installation: Pre-drilled holes provide multiple mounting options for a fast and hassle-free setup.
  • Plug-and-Play: MC4 connectors with 3ft pre-attached cables for easy connection to other solar panels.
  • 1.3mm Thick Aluminum Frame – Reinforced for strength and corrosion resistance, ensuring long-lasting outdoor performance.

Why Choose RICH SOLAR

RICH SOLAR has been a leader in the off-grid solar industry since 2005, with a focus on bringing the world's best solar products to market while providing world-class customer service.

Free Shipping
U.S. Local Warehouse
Lifetime Service

WARRANTY

Warranty: This product is covered by the official RICH SOLAR manufacturer limited warranty. Warranty terms, coverage period, and claim requirements are provided by RICH SOLAR.

View RICH SOLAR Warranty Details
